HID Projector Comparisons

Discussion in 'Lighting, HID's, And Retrofitting' started by webby, Apr 14, 2013.

  1. webby
    • Staff
    • 2018 Toys For Tots

    webby Administrator

    Messages:
    49,881
    [​IMG]

    Little explanation of how each photo was taken:
    I tried to place the cutoff shield step near the center line on the wall. Each of the concrete slabs were 14ft wide. The midpoints are marked by pieces of paper at 7ft. These are just points so you can gauge each picture and compare their properties. All of the shots were taken on a tripod at 25ft from the wall.

    Each photo was taken in manual camera mode. They were taken at 400iso at F8 for 2 seconds. If one picture looks brighter or darker, that is a characteristic of the projector. With each photo being taken with the same properties, the camera will not adjust to make them all look the same as far as brightness etc. There are zero adjustments to color, contrast, brightness, sharpness etc in photoshop.

    H1 Bulb - generic 6000k ebay bulb
    All other photos: Generic D2S 6000k ebay bulb (unless otherwise noted).

    On to the pics

    Mini D2S (orasm bulb)
    [​IMG]

    Acura TSX Fresnel Lens
    [​IMG]

    Acura TSX OEM Clear Lens
    [​IMG]

    Mini H1 Low Beam
    [​IMG]

    Mini H1 High Beam
    [​IMG]

    Acura TL Fresnel Lens
    [​IMG]

    Acura TL Fresnel Lens High Beam
    [​IMG]

    Honda S2000 AP1 OEM Clear Lens
    [​IMG]


  2. CivicCanuck

    CivicCanuck Well-Known Member

    Messages:
    782
    Location:
    North
    Vehicle Model:
    Civic
    From those pictures, it looks like the Mini H1 is really great! Were all of the projectors installed in a housing with the same height, or were they bare and aimed by hand?

    AlienPrime likes this.
  3. 420Coupe

    420Coupe Well-Known Member

    Messages:
    475
    Vehicle Model:
    LX
    Body Style:
    Coupe
    god such a crisp cut off from the AP1's i should have gone with those instead of the 3" FX-R's they've turned into such a project to get them to fit

  4. ethlar
    • Staff

    ethlar Grumpy Moderator

    Messages:
    4,173
    Location:
    TX
    Vehicle Model:
    TLX 3.5 SH-AWD Tech
    Body Style:
    Sedan
    about how far away from the wall are you for the pictures

  5. 420Coupe

    420Coupe Well-Known Member

    Messages:
    475
    Vehicle Model:
    LX
    Body Style:
    Coupe
    about 25ft, labeled at the bottom of every picture

    Last edited: Apr 14, 2013
  6. ethlar
    • Staff

    ethlar Grumpy Moderator

    Messages:
    4,173
    Location:
    TX
    Vehicle Model:
    TLX 3.5 SH-AWD Tech
    Body Style:
    Sedan
    :pat: thanks, i only looked at the specs on the first picture not the rest of them

  7. webby
    • Staff
    • 2018 Toys For Tots

    webby Administrator

    Messages:
    49,881
    All of the projectors were at 25ft on a little stool. They are not in a headlight housing. It's just the bare projector sitting on a stool. The height differences just has to do with how the projector was aimed to get it to lay level while snapping the pic. I had to put random objects under some to get them to lay level without tipping over.

  8. CivicCanuck

    CivicCanuck Well-Known Member

    Messages:
    782
    Location:
    North
    Vehicle Model:
    Civic
  9. AlienPrime

    AlienPrime Well-Known Member

    Messages:
    3,058
    Location:
    Sudbury, Ontario, Canada
    Vehicle Model:
    Civic Si HFP
    Body Style:
    2 door Coupe
    Great job webby!!! :D:D

    Pauly99to17 likes this.
  10. Nix

    Nix J├Âtunn Moderator

    Messages:
    10,765
    Location:
    Lew-vul, KY
    Body Style:
    It's A Fast Pig!
    Nice! The mini looks really sharp. More to come?

    AlienPrime likes this.
  11. austin1636

    austin1636 Well-Known Member

    Messages:
    199
    Location:
    Gresham
    Vehicle Model:
    civic si
    Body Style:
    sedan
    I really like the TSX, but the mini h1 isn't bad at all

  12. webby
    • Staff
    • 2018 Toys For Tots

    webby Administrator

    Messages:
    49,881
    I'm going to redo the whole thing at another location maybe this week with some better shots. I have some aftermarket clear lenses I'll demonstrate as well. The original spot I planned to use was filled with cars, so I had to resort to this spot. I don't have any other projectors to show at this point. I'd be more than happy to test more if someone wants to loan me something. I'd pay for insured shipping both ways.

  13. FAPPY

    FAPPY Well-Known Member

    Messages:
    286
    Vehicle Model:
    Si
    Body Style:
    Coupe
    seems the whole retrofit thing is getting popular. its the first thing I did to my car and it was money well spent.

    Nix likes this.
  14. 323

    323 Modifier

    Messages:
    5,252
    Location:
    Chicago
    Vehicle Model:
    Civic Si
    Body Style:
    Sedan
    I like the Mini H1's, cutoff and color looks great

    AlienPrime likes this.
  15. Nomar06
    • Staff

    Nomar06 Super Moderator

    Messages:
    7,412
    Location:
    Charlotte, NC
    Vehicle Model:
    Fiesta ST (FiST)
    Body Style:
    hatch
    The mini H1 uses HID bulb? The whiteness in the light seems way better.

    I have some D2S 5000k bulbs sitting around if you want to use.

  16. webby
    • Staff
    • 2018 Toys For Tots

    webby Administrator

    Messages:
    49,881
    Pauly99to17 and AlienPrime like this.
  17. webby
    • Staff
    • 2018 Toys For Tots

    webby Administrator

    Messages:
    49,881
    The bulbs are from the same company rated 6k. The only one that isn't 6k is the projector in the 1st pic (with the orasm d2s bulb). I just wasn't thinking when I didn't swap the bulb into that projector at the end. It had a bulb already in it from messing around earlier. I'll run the orasm d2s in the others to see how they compare in the next test.

  18. dirtybird222

    dirtybird222 Well-Known Member

    Messages:
    268
    Location:
    '
    Vehicle Model:
    Civic Si
    Body Style:
    Sedan
    Oh my god tell me about it. I've completely trashed the reflector bowls in this project trying to get the fx-rs to fit with a panamera shroud. Mounting the FX-Rs to the headlight housing now. I do not like the 3.0 design for mounting and so on the 2.0 was much easier to work with. I will most likely purchase a set of these though for my wifes car.

  19. AlienPrime

    AlienPrime Well-Known Member

    Messages:
    3,058
    Location:
    Sudbury, Ontario, Canada
    Vehicle Model:
    Civic Si HFP
    Body Style:
    2 door Coupe
    i think i can say mini H1 are without a doubt the cleanest cutoff.. who agrees?! :D

  20. ethlar
    • Staff

    ethlar Grumpy Moderator

    Messages:
    4,173
    Location:
    TX
    Vehicle Model:
    TLX 3.5 SH-AWD Tech
    Body Style:
    Sedan
    Just wait till webby posts the tuned up s2k and tl-zkw combo
